Matrix Cosec Path RDFI

Matrix Cosec Path RDFI Specification

Automation Grade
Automatic

Display Type
3.5 TFT color touchscreen

Size
50 x 185 x 43 mm

Accuracy
FAR 0.001% / FRR 0.1%

Usage & Applications
Industrial, Corporate Offices, Manufacturing Units

Installation Type
Wall Mount

Weight
Approx 0.4 kg

Operating System
Linux Embedded

Data Capacity
9,600 fingerprints, 25,000 cards, 5,00,000 events

Power Supply
12V DC

Interface
Ethernet, RS485

Scan Speed
<0.5 sec

Connectivity Type
Ethernet, RS485, Wi-Fi (optional)

Features
IP65 Rated, PoE, Touch Sense Keypad, Voice guidance

Type
Access control

Material
Metal

Usage
Industrial

Identification Mode
Fingerprint

Identification Time
<0.5 sec

Power
12V DC, 500mA

Controller to Reader Distance
Up to 100m via RS485

Template Storage Capacity
9,600 finger templates

Communication
Ethernet, RS485, Wi-Fi (Optional), USB

Keypad
Touch Sense Keypad

PoE Support
Available (Optional)

Audio
Voice guidance

Humidity
5% to 85% RH Non-condensing

Protection
IP65 Rated for dust and water resistance

Mounting
Wall or Back Panel Mount

Operating Temperature
0°C to 50°C

Event Log
5,00,000 logs

Card Storage Capacity
25,000 cards

Matrix Cosec Path RDFI Trade Information

Minimum Order Quantity
5 Units

Payment Terms
Cash Advance (CA), Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
7 Days

Main Domestic Market
All India

About Matrix Cosec Path RDFI

Product Details:

Minimum Order Quantity	1 Piece
Model Name/Number	COSEC PATH RDF - EM/Mifare
Sensor Type	Optical Sensor
Installation Type	Wall Mounted
Display Type	LCD
Brand	Matrix
Connectivity Type	Wired
Language	English
Color	Black
Usage/Application	Fingerprint and card based Access Control Reader
Certifications	IP65
Reader Type	Fingerprint, Proximity
Type Of Device	Access control
Products Included	Machine

Comprehensive Access Control Made Simple

Designed for modern industries, the Matrix Cosec Path RDFI combines biometric authentication and card access to ensure only authorized personnel gain entry. It manages thousands of users with swift identification in less than 0.5 seconds and logs up to half a million events, supporting large-scale operations efficiently. This system secures premises while optimizing workflow, aided by intuitive voice guidance and a responsive touch keypad.

Built for Industrial Durability and Seamless Connectivity

Constructed from sturdy metal and rated IP65, the Matrix Cosec Path RDFI resists dust, water, and physical wear, making it perfect for rugged environments. It supports Ethernet, RS485, optional Wi-Fi, and USB connectivity, ensuring flexible installation and network integration. With PoE support (optional) and wall or back panel mounting options, it adapts effortlessly to varied application needs.

FAQ's of Matrix Cosec Path RDFI:

Q: How does the Matrix Cosec Path RDFI identify and authenticate users?

A: The device uses biometric fingerprint recognition and RFID card authentication, offering both single and dual-factor modes. It verifies identities swiftly, identifying users in less than 0.5 seconds, ensuring secure yet efficient access control.

Q: What is the process for installing and configuring this access control system?

A: Installation is straightforward-it can be wall or back panel mounted. Configuration is managed via its embedded Linux OS and a 3.5" TFT touchscreen. Connectivity through Ethernet, RS485, or optional Wi-Fi allows easy integration into existing infrastructure.

Q: Where is the Matrix Cosec Path RDFI most effectively used?

A: Ideal for industrial environments such as manufacturing units, power plants, and corporate offices, this device thrives where durability, security, and high capacity are prioritized. Its IP65 rating and robust build make it suitable for demanding workplaces.

Q: What communication options does the device support?

A: The Matrix Cosec Path RDFI supports Ethernet, RS485, USB, and optional Wi-Fi for versatile communication. Additionally, Power over Ethernet (PoE) is available as an option, offering flexible power and network connectivity.

Q: When should I consider using this access control system over traditional methods?

A: Choose the Matrix Cosec Path RDFI when you need secure, scalable, and reliable access control with biometric accuracy, comprehensive logging, and integration flexibility-superior to traditional, less-secure key or keypad systems.

Q: How does the device protect against environmental hazards?

A: With its IP65-rated metal casing, the system resists dust and water ingress, ensuring long-lasting performance in tough industrial environments exposed to moisture and airborne particles.

Q: What are the main benefits of deploying the Matrix Cosec Path RDFI?

A: Key benefits include advanced security with biometric accuracy, rapid identification, extensive user and event storage, flexible connectivity, durability in harsh environments, and user-friendly operation through its touchscreen and voice guidance.
